This document describes important tuning parameters and settings that can result in improved performance for your Microsoft® Windows Server™ 2003 system. Each setting and its potential effect are described to help you make an informed judgment about its relevance to the system, workload, and performance goals.
The information contained in this document represents the current view of Microsoft Corporation on the issues discussed as of the date of publication. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information presented after the date of publication.
This White Paper is for informational purposes only. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS DOCUMENT.
Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the express written permission of Microsoft Corporation.
Microsoft may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from Microsoft, the furnishing of this document does not give you any license to these patents, trademarks, copyrights, or other intellectual property.
Microsoft® Windows Server™ 2003 should perform very well out of the box for most customer workloads. However, it is possible to tune the server settings and see incremental performance gains, especially when the nature of the workload will not vary much over time.
The most effective tunings take into account the hardware, the workload, and the performance goals. This document describes important tuning parameters and settings that can result in improved performance. Each setting and its potential effect are described to help you make an informed judgment about its relevance to the system, workload, and performance goals.
Note: Registry settings and tuning parameters may have changed significantly from Microsoft Windows® 2000 Server to Windows Server 2003. Please keep this in mind as you tune your server—using earlier or out-of-date tuning guidelines may produce unexpected results.
The network architecture covers many components, interfaces, and protocols; Figure 1 illustrates some of them. The sections below discuss tuning guidelines for some of the components for server workloads.
F igure 1 Network Stack Components
The network architecture is layered, and the layers can be broadly divided into:
The network driver and NDIS. These are the lowest layers. NDIS exposes interfaces for the driver below it and for the layers above it; for example, TCP/IP.
The protocol stack. This implements protocols such as TCP/IP and UDP/IP. These layers expose the TDI interface for layers above them.
System Drivers. These are typically TDI clients and expose interfaces to user-mode applications. The WinSock interface is exposed by Afd.sys.
Tuning for network-intensive workloads can involve tuning for each of the layers. Some of the tunings are described below.
Offloading tasks can help lower CPU usage on the server, improving overall system performance. The Microsoft TCP/IP transport can offload one or more of the following tasks to a network adapter that has the appropriate task-offload capabilities:
Checksum tasks.The TCP/IP transport can offload the calculation and validation of IP and TCP checksums for sends and receives.
IP security tasks. The TCP/IP transport can offload the calculation and validation of encrypted checksums for authentication headers (AH) and encapsulating security payloads (ESP). The TCP/IP transport can also offload the encryption and decryption of ESP payloads.
Segmentation of large TCP packets. The TCP/IP transport supports large send offload (LSO). With LSO, the TCP/IP transport can offload the segmentation of large TCP packets.
Stack offload. The entire network stack can be offloaded to a network adapter that has the appropriate capabilities.
Some network adapters are capable of moderating how frequently they interrupt the host processors to indicate network activity (or its completion). Some network adapters are also capable of making such decisions in an adaptive manner, taking into account network and host-processor load. Moderating interrupts can often result in reduction in CPU load on the host, but unless interrupt moderation is performed intelligently and adaptively, the CPU savings may come at the cost of increases in latency.
Network adapters that are 64-bit capable can perform direct memory access (DMA) operations to and from high physical memory locations (above 4 GB).
Copper and Fiber Network Adapters
Copper network adapters have the same performance as their fiber counterparts, but may be less expensive to purchase. The cost of the transceiver on copper network adapters is lower.
These network adapters are good for failover scenarios but share a single interrupt among all the ports on the network adapter. Using two single-port network adapters usually yields better performance than using one dual-port network adapter for the same workload.
